Okuma Ceymar HD Spinning Reel

$129.99
$129.99
Sale Sold out

SKU: 840083417834

SUPPLIER CODE: CHD-3000A

Shipping calculated at checkout.
Model

INSPIRED BY PERFORMANCE

The brand new Ceymar HD is designed and developed based on the concept of Power! The Ceymar HD features HDG-II – High Density, Oversized Gearing, aluminum screw-in handle and a gear stabilization system providing the ultimate in strength and cranking power. In addition, the Flite Drive™ effectively reduces rotational resistance, delivering not only strength, but also an unrivaled lightweight and smooth feel.



Features

  • HDG-II: Oversized high-density gearing
  • EFR-II: Even Flow Roller system with DLC coating
  • Lightweight and machined aluminum screw in handle design
  • Gearing stabilization design
  • Flite Drive™
  • Precision machine cut brass pinion gear
  • Heavy duty, solid aluminum bail wire
  • Rotor brake
  • Lightweight and machined aluminum spool
  • Multi-disc, Japanese oiled felt drag system
  • 7+1 for ultimate smoothness
  • Quick-Set anti-reverse roller bearing



Technology



HDG-II: High Density Gearing II Oversized Main Gear

Under the original high-strength HDGII, Okuma has enlarged the main gear to provide better strength and a higher gear ratio. Taking the 3000 sizes as an example, the Ceymar HD main gear is larger than the standard gearing by 7%.






Gearing Stabilization Design

Provides excellent support on the top, middle and bottom of the pinion gear, making the gears extremely stable and durable.






Flite Drive™

In most reels, when the main shaft is moved up and down, a large area of friction is generated within the pinion gear which causes you to feel resistance when turning the handle. To reduce drag and achieve a free rotation, we hollowed out the center of the pinion to reduce friction with the shaft. This change to the pinion gear creates the ultimate in stabilization and a friction-free handle winding experience.






Diamond-Like Carbon (DLC): Even Flow Roller System With DLC Coating

The EFR II with DLC coating greatly reduces line friction allowing the fishing line to run more smoothly over this smooth surface, prolonging the life of the fishing line and the prevention of line twist.




Light Weight And Machined Aluminum Screw-In Handle Design






Specifications

CEYMAR HD STANDARD-SPEED SPINNING REELS
MODEL

GEAR
RATIO

 BEARINGS

WEIGHT
(G)

LINE
RETRIEVE (CM)

MAX DRAG
FORCE (KG)

MONO LINE CAPACITY
(DIAMETER IN MM.)
CHD-1000A 5.2:1 7BB+1BB 196 68 5 0.15/255, 0.20/140, 0.25/90
CHD-2500A 5.3:1 7BB+1BB 235 78 6 0.20/250, 0.25/165, 0.30/110
CHD-3000A 5.3:1 7BB+1BB 235 78 6 0.20/310, 0.25/200, 0.30/130
CHD-4000A 5.2:1 7BB+1BB 273 83 9 0.25/280, 0.30/185, 0.35/130
CHD-C5000A 5.2:1 7BB+1BB 276 88 9 0.30/240, 0.35/170, 0.40/125
CHD-1000SA 5.2:1 7BB+1BB 196 68 5 PE0.4(0.104mm)-100m
PE0.6(0.128mm)-60m
PE0.8(0.148mm)-40m
CHD-3000SA 5.3:1 7BB+1BB 234 78 6 PE0.6(0.128mm)-210m
PE0.8(0.148mm)-150m
PE1.0(0.165mm)-125m



CEYMAR HD HIGH-SPEED SPINNING REELS
MODEL

GEAR RATIO

 BEARINGS

WEIGHT (G)

LINE RETRIEVE (CM)

MAX DRAG FORCE (KG)

MONO LINE CAPACITY
(DIAMETER IN MM.)
CHD-1000HA 6.0:1 7BB+1BB 196 79 5 0.15/255, 0.20/140, 0.25/90
CHD-2500HA 6.0:1 7BB+1BB 235 88 6 0.20/250, 0.25/165, 0.30/110
CHD-3000HA 6.0:1 7BB+1BB 235 88 6 0.20/310, 0.25/200, 0.30/130
CHD-4000XA 6.2:1 7BB+1BB 273 99 9 0.25/280, 0.30/185, 0.35/130
CHD-C5000XA 6.2:1 7BB+1BB 276 105 9 0.30/240, 0.35/170, 0.40/125
CHD-1000SHA 6.0:1 7BB+1BB 196 79 5 PE0.4(0.104mm)-100m
PE0.6(0.128mm)-60m
PE0.8(0.148mm)-40m
CHD-3000SHA 6.0:1 7BB+1BB 234 88 6 PE0.6(0.128mm)-210m
PE0.8(0.148mm)-150m
PE1.0(0.165mm)-125m
